HDPE STUDDED MEMBRANE 8mm/400 GSM
PROPERTY	METHOD	UNITS	VALUE
Mass per Unit Area	EN 1SO 9864	GSM	400
Dimple Height	EN 9863-1	mm	8
Compressive Strength	EN12311-2	kPa	150
Tensile Strength	EN 12311-2	N/50MM	>200/>200
Air gap volume between dimples		l/ sqm	5
Drain flow capacity in plane	EN 12958	l/sqm/s	2.8
Elongation	EN 12311-2	%	>20/>25
Width		M	2.3
Length		M	20
Reaction to fire			Class ‘E’
PROCEDURE The INDOKON Dimple Board should be fixed for vertical application on the wall, ensuring the bubbles face towards the wall. A minimum overlap of 10 cm should be maintained between the sheets. Overlaps can be sealed with glue-insulated tapes. In the case of horizontal application, INDOKON Dimple Board will be laid with bubbles facing the ground and an overlap of 10 cm between the sheets. Overlaps can be further reinforced with glue-insulated tapes.
STORAGE ● Rolls must not be exposed directly to UV radiation for over a month. ● Rolls must be stored in their original package horizontally under a cool and dry condition. ● Rolls should be protected from direct sunlight, rain, etc.

Download Brochure →

DiBo 10
INDOKON Dimple Drain board is specifically designed for use with all waterproofing membrane systems as well as any torch-applied waterproofing membranes surface. It is made of high density polyethylene (HDPE). It is light weight, flexible, strong, durable, non-toxic, dimple sheet board with 10.0 mm deep dimples. It is impermeable to water and water vapour. It is an efficient, filtered sub-soil drainage system used for drainage of all in- ground structures. It comprises a highly compression resistant and flexible studded plastic dimple core.
Properties	Unit	Value
Drainage Core		HDPE
Thickness @ 2 kPa [EN ISO 9863-1]	mm	10.0 [±10%]
Compressive Strength [ASTM D1621]	kPa	˃150
Sheet Thickness	mm	0.50
Hydraulic Properties
In Plane Water Flow i=1.0 @ 100 kPa [EN ISO 12958]	l/m.s	4.25
Product Dimensions
Roll Width Roll Length	m m	2.30 20.00

Notes ‐ Reported value are arithmetic mean values unless otherwise stated, A set of test results derived from specimens cut from one sample and taken across full width of the roll. ‐ The above properties might change at the time of the manufacturing, storing, handling or shipping. ‐ There may be variation in above values due to various factors when tested at other laboratory.

Download Brochure →

DiBo 13 (HDPE Dimple Board)
INDOKON Dimple Drain board is specifically designed for use with all waterproofing membrane systems as well as any torch-applied waterproofing membranes surface. It is made of high density polyethylene (HDPE). It is light weight, flexible, strong, durable, non-toxic, dimple sheet board with 13 mm deep dimples. It is impermeable to water and water vapour. It is an efficient, filtered sub-soil drainage system used for drainage of all in-ground structures. It comprises a highly compression resistant and flexible studded plastic dimple core.
Properties	Unit	Value
Drainage Core		HDPE
Thickness @ 2 kPa [EN ISO 9863-1]	mm	13.0 [±10%]
Compressive Strength [ASTM D1621]	kPa	˃150
Sheet Thickness	mm	0.50
Hydraulic Properties
In Plane Water Flow i=1.0 @ 100 kPa [EN ISO 12958]	l/m.s	5.00
Product Dimensions
Roll Width Roll Length	m m	2.30 20.00

Notes ‐ Reported value are arithmetic mean values unless otherwise stated, A set of test results derived from specimens cut from one sample and taken across full width of the roll. ‐ The above properties might change at the time of the manufacturing, storing, handling or shipping. ‐ There may be variation in above values due to various factors when tested at other laboratory.

Download Brochure →

HDPE STUDDED MEMBRANE 8mm (with prefixed geotextile)
PROPERTY	METHOD	UNITS	VALUE
Sheet Thickness		mm	0.5
Mass per Unit Area	EN 1SO 9864	GSM	500
Polypropylene Geotextile		GSM	150
Total Weight		GSM	650
Dimple Height	EN 9863-1	mm	8
Compressive Strength	EN12311-2	kPa	250
Tensile Strength	EN 12311-2	N/50MM	>200/>200
Air gap volume between dimples		l/ sqm	5
Drain flow capacity in plane	EN 12958	l/sqm/s	2.8
Elongation	EN 12311-2	%	>30/>30
Width		M	2.3
Length		M	20
Reaction to fire			Class ‘E’

PROCEDURE INDOKON Dimple Board should be fixed for vertical application on the wall, ensuring the bubbles face towards the wall. A minimum overlap of 10 cm should be maintained between the sheets. Overlaps can be sealed with glue-insulated tapes. In the case of horizontal application, INDOKON Dimple Board will be laid with bubbles facing the ground and an overlap of 10 cm between the sheets. Overlaps can be further reinforced with glue-insulated tapes.
STORAGE ● Rolls must not be exposed directly to UV radiation for over a month. ● Rolls must be stored in their original package horizontally under a cool and dry condition. ● Rolls should be protected from direct sunlight, rain, etc.

Download Brochure →

DiBo 10G (Drain Board with prefixed geotextile)
INDOKON drainage layer comprising a high a performance Single Cuspated HDPE (High Density Polyethylene) Core with a geotextile filter thermally bonded to one Side.The Product is practically impermeable on one side. It is used for drainage of all underground ground structures. It comprises a highly compression resistant.
Properties	Unit	Value
Drainage Core		HDPE
Dimple Height @ 2 kPa [EN ISO 9863-1]	mm	10.00
Compressive Strength [ASTM D 1621]	kN/m²	≥400
Compressive Strength (Permanent Loading)	kN/m²	≥90
Tensile Strength [EN ISO 10319]	kN/m	˃6.0
Air gap Between Dimples	l/m²	7.90
Hydraulic Properties
In Plane Water Flow
@ No Load [EN ISO 12958]	l/m.s	3.50
@ 20 kPa [EN ISO 12958]	l/m.s	3.10
Geotextile Properties		Polypropylene
Thickness @ 2 kPa [EN ISO 9863-1]	mm	0.90 [±0.1]
Dynamic Perforation Cone Drop Test [EN ISO 13433]	mm	40.0 [+8]
Opening Size (AOS) [EN ISO12956]	µm	150
Product Dimensions
Roll Width	Mtr.	2.30
Roll Length	Mtr.	20.0
Notes ‐ Reported value are arithmetic mean values unless otherwise stated, A set of test results derived from specimens cut from one sample and taken across full width of the roll. ‐ The above properties might change at the time of the manufacturing, storing, handling or shipping. ‐ There may be variation in above values due to various factors when tested at other laboratory.

Download Brochure →

DiBo 13G (Drain Board with prefixed geotextile)
INDOKON Geocomposite drainage layer comprises of a high performance Single Cuspated HDPE (High Density Polyethylene) Core with a geotextile filter thermally bonded to one Side. The Product is practically impermeable on one side. It is used for drainage of all underground ground structures. It comprises a highly compression resistant.
Properties	Test Method	Unit	Value Mean (with tolerance)
Geocomposites		-
Thickness @2 kPa	EN ISO 9863-1	mm	13.0 [±10%]
Mass Per Unit Area	EN ISO 9864	g/m²	895 [5.0%]
Tensile Strength MD / CMD Elongation @ Peak MD / CMD	EN ISO 10319	kN/m	10.0 \| 10.0 [±10%]
Tensile Strength MD / CMD Elongation @ Peak MD / CMD	EN ISO 10319	%	45.0 \| 45.0 [±10]
CBR Puncture	EN ISO 12236	N	1800 [±10%]
Hydraulic Properties		-	-
In Plane Water Flow i=1.0	EN ISO 12958	l/m.s	-
@ 20 kPa			3.50
@ 20 kPa			3.40
@ 20 kPa			3.15
Drainage Core		-	High Density Polyethylene (HDPE)
Thickness @ 2 kPa	EN ISO 9863-1	mm	13.0 [±10%]
Compressive Strength	ASTM D1621	kPa	˃150
Sheet Thickness	-	mm	0.50
Air gap between dimples	-	l/m²	7.90
Hydraulic Properties		-	-
In Plane Water Flow i=1.0	EN ISO12958	l/m.s	-
@ 20 kPa			5.50
@ 100 kPa			5.00
@ 200 kPa			4.50
Geotextile		-	-
Thickness @ 2 kPa	EN ISO 9863-1	mm	1.00 [±10%]
Mass per Unit Area	EN ISO 9864	g/m²	145 [±10]
Tensile Strength MD/CD	EN ISO 10319	kN/m	8.00 \| 8.00 [±10%]
CBR Puncture Resistance	EN ISO 12236	N	1500 [-150]
Dynamic Perforation Cone Drop	EN ISO 13433	mm	32 [+8]
Water permeability	EN ISO 11058	l/m²/sec	70.0 [±20%]
Apparent Opening Size	ASTM D4751	Micron	180 [±20%]
Product Dimensions		-	-
Roll Width		Mtr.	2.30
Roll Length		Mtr.	20.00
Notes ‐ Reported value are arithmetic mean values unless otherwise stated, A set of test results derived from specimens cut from one sample and taken across full width of the roll. ‐ The above properties might change at the time of the manufacturing, storing, handling or shipping. ‐ There may be variation in above values due to various factors when tested at other laboratory.

Download Brochure →

Specification (350gsm, 50% Straw and 50% Coir mixed Blanket with Brown PP net and Brown PP thread)
Material	50% Straw and 50% Coir, Brown Photodegradable PP net and PP thread PP netting is -Photodegradable
Dimensions	Width Upto 2.4m, Length Upto 50m
Thickness	5-6mm (tested according to ASTM D 5199)
Apparent opening Size	Nil (tested according to ASTM D 4751)
Mass (g/sqm)	340-360g (tested according to ASTM D 5261)
Tensile Strength (kN/m)	MD – 2.95 (tested according to ASTM D 4595)
Tensile Strength (kN/m)	Cross 1.52
Elongation at Break	md 31% (tested according to ASTD 6818) Cross md 23 %
** Longevity depends on location factors, soil- water- and climate conditions as well as on the local risk of erosion on site.
Installation:
Vegetation Establishment– Seeding can be undertaken prior to blanket installation and seedlings can grow up through the blanket. Alternatively seeding can undertake after installation and sown on to the blanket.

Hydro seeding is also an effective seed application method over large areas and will provide further support for vegetation growth. Wildflower and aquatic plants and shrubs can be inserted through the coir mesh after installation and the blanket will provide support to vegetation establishment.
Overlapping and Anchorage –Sufficient overlap and anchorage is the key to the success of erosion control blanket products.

Specification (700gsm- PP Net Both Sides stitched with Black PP thread)
Material	100% Core Fiber, PP Net & PP Thread
	PP Netting is - Photodegradable
	Mesh- 13mm X 13mm
Dimensions	Width Upto 2m, Length Upto 50m
Thickness	7-8.5mm (tested according to ASTM D 5199)
Apparent opening Size	Nil (tested according to ASTM D 4751)
Mass (g/sqm)	690-710g (tested according to ASTM D 5261)
Tensile Strength (kN/m)	MD – 4.46 (tested according to ASTM D 4595)
Tensile Strength (kN/m)	CD - 2.93
Elongation (N)	MD- 31% (tested according to ASTD 6818)
	CD - 13.2%
Installation:
Vegetation Establishment– Seeding can be undertaken prior to blanket installation and seedlings can grow up through the blanket. Alternatively seeding can undertake after installation and sown on to the blanket.

Hydro seeding is also an effective seed application method over large areas and will provide further support for vegetation growth. Wildflower and aquatic plants and shrubs can be inserted through the coir mesh after installation and the blanket will provide support to vegetation establishment.
Overlapping and Anchorage –Sufficient overlap and anchorage is the key to the success of erosion control blanket products.

Coir Erosion Control Blanket - 450 GSM (w/o straw) Specifications
Fiber Materials	Fiber: 100% coconut fiber
	Netting: Top - Size: Black Polypropylene net; Netting Weight - 7.2GSM Netting: Bottom -Size: Black Polypropylene net; Netting Weight - 7.2GSM Thread: Black Polypropylene
	Mesh 13mm x 13mm
Dimensions	Width – 2m/ 2.4m \| Length - 50m
Dimensions	Area of rolls – 100 / 120SQM
Functional Longevity	3-4 Years
STANDARDS
Tensile Strength ISO-10319	295.5 lbs/ft MD (4.02kN/m) -ASTM D5035
D4595 Elongation	14.6% MD - ASTM D5035
D4491 Flow Velocities	12.00 ft/s (3.05 m/s)
Max Permissible Shear Stress	2.45 lbs/ft2 (108Pa) (UNVegetated Shear Stress)
PP SPECIFICATION
Tensile Strength	4.78 MD kN/m
Tensile Strength	3.65 TD kN/m
Yield Point Elongation	20% MD
Yield Point Elongation	15% TD
Mesh Shape	Quadrangular
Colour	Black
MD Pitch/ TD Pitch	13mm/ 13mm
Thread	UV Stabilized Polypropylene

Modern Solutions for Wet Basements: Using Dimple Boards for Interior Drains

The Ultimate Guide to Foundation Protection: Why HDPE Dimple Boards are Essential
